Orange Color Pet Blowing Machine , Plastic Bottle Blowing Molding Machine

Name: Orange Color Pet Blowing Machine Plastic Bottle Blowing Molding Machine
Brand: Eceng
Price: 1 USD

Brand Name : Eceng

Model Number : q3000

Certification : ce , iso

Place of Origin : Zhangjiagang

MOQ : 1

Payment Terms : L/C, T/T, MoneyGram

Delivery Time : 45 days

Packaging Details : woden package

Application : pet bottle making machine

Condition : new

Blow moulding type : stretch blow moulding

Automatic : yes

Voltage : 380V/50HZ

Weight : 2.5tons

material : pet preform

color : orange

Contact Now

Orange Color Pet Blowing Machine , Plastic Bottle Blowing Molding Machine

1,Infrared lamps adoped in the pre-heater ensures PET preforms being heated evenly.
2,Mechanical-double-arm calmping ensures mould being tightly closed under hight pressure and high temperature.
3,Pneumatic system consists of two parts. pneumatic acting part and bottle blowing part in order to meet different requirements for both acting and blowing. It provides sufficient steady high pressure to blowing. It provides sufficient steady high pressure to bloww large irregular shape bottles.
4,Equipped with silencer and oiling system to lubricate the mechanical pars of the machine.
5,Wide-mouth jar and hot-fill bottles can also be made.

Orange Color Pet Blowing Machine , Plastic Bottle Blowing Molding Machine

Model		Q3000
Bottle type specification	Cavity	2
	Theory output	3000-4000
	Max.volume	2L
	Bottle mouth maximum overall diameter	28-38mm
	Bottle biggest diameter	100mm
	Bottle maximum height	330mm
Power specification	Light tube quantity	16pcs
	Light tube power	1.5KW
	Maximum heating power	24KW
	All electric machine installation	27KW
	Actual consumption	40%--70%
Air pressure specification	Work pressure	7-9kg/cm2
	Low-pressure gas consumption	1000L/min
	Blow bottle pressure	25-35kg/cm2
	Higher -pressure gas consumption	3000Ltr/min
Air pressure specification	Work pressure	5-6kg/cm2
	Temperature range	10℃
	Consumption	8000kcal/hr
	Forzen water flow	88L/min
Machine specification	Machine size	2.6x1.7x1.9
Machine specification	Machine weight	2.5ton

Orange Color Pet Blowing Machine , Plastic Bottle Blowing Molding Machine
