Technology Project Ideas new condition Pet Bottle Blowing Machine
1) The complete drinking water plant has suspending bottle-neck clamping design make the bottle stable during the high-speed moving conditions. By changing a few parts, it can meet the need of production of different types of bottles easily.
2) The new generation of stainless steel grab is adopted and the grabs have no contact with the area above the bottle"s screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
3) The advanced gravity filling technology used in this machine makes the filling quick , steady and accurate.
4) Magnetic torque is used for screw capping, and the power of screw capping can be adjusted steplessly. Capping is reliable and do no harm to the caps.
5) Advanced technologies, such as human-machine interface touch-screen and PLC program control are adopted in this mineral water plant machine.
6) All parts that have direct contact with the water are made of high quality stainless steel. The critical electrical components are from famous international companies, such as Mitsubishi, Omron to name a few.
General Specifications
-
| Specification | Gathers the moldstrenghth ( KN) | 160 | The theory produces energy(BPH) | | 2000-2300 |
| Mold traveling schedule(mm) | 135 | Electric power specification | Total power consumption(KW) | 25 |
| Pulls rises the traveling schedule(mm) | 280 | Thermal rating(KW) | 24 |
| Jar Spacing | | Air pressure specification | Service pressure(kg/cm2) | 8 |
| Mold hole number(cavity) | 2 | Low pressure gas consumption(1tr/min) | 1300 |
| Bottle specification | bottle maximum capacity(L) | 0.7 | Blows the bottle pressure(Kg/cm2) | 30 |
| Max. tooth department size(mm) | 40 | High-pressured gas consumption(1tr/min) | 1500 |
| Max.Bottle diameter | 70 | Machine weight | Machine size(M) | 2.5*1.9*2.2 |
| Max.Bottle body height(mm) | 280 | Machine weight(T) | 2.3 |
Main Parts
| No. | Part Name | Brand |
| 1 | cylinder | FESTO(Germany) |
| 2 | magnetic valve | FESTO(Germany) |
| 3 | atomized lubricator oil-water separator Low pressure relief valve | FESTO(Germany) |
| 4 | high-pressure valve | PARKER (U.S.A) |
| 5 | proximity switch | OMRON(JAPAN) |
| 6 | touch screen | TAIWAN WEI LUN |
| 7 | converter | Mitsubishi(JAPAN) |
| 8 | seal ring | ITALY |
| 9 | PLC | Mitsubishi(JAPAN) |
| 10 | high-pressure valve | SMC(JAPAN) |
