PID Control Compressed Air Chiller , Industrial Cooling Systems Chillers

Name: PID Control Compressed Air Chiller Industrial Cooling Systems Chillers
Brand: Eceng
Price: 1 USD

China PID Control Compressed Air Chiller , Industrial Cooling Systems Chillers wholesale

Brand Name : Eceng

Model Number : YC-5P

Certification : CE&SGS&ISO

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 15set per month

Delivery Time : 15 working days

Packaging Details : Film pack

warranty : 1 year

Dimension : 1250*600*1250 mm

Evaporator : Tank & Coil

weight : 170KG

Application : Industrial Cooling

Cooling capacity : 14kw

Contact Now

China Manufacturer 5 hp Air Cooled Water Chiller Price

Features of Air Cooled Chiller

1,Newest imported compressors and high-efficient condenser,evaporator, strong cooling ability, silent and energy-saving, micro-computer comprehensive control, easy operation(optional).
2,Adopting newest stainless-steel open style water tank, convenient to clean and maintain.
3,Current overloaded protection, Low & High pressure protection and electronic time delaying protection device and other abnormal condition indication system.
4,Screen liquid crystal display of chill water outlet and inlet with temperature setting (Options available)
5,Elegant appearance through industrial design.

PID Control Compressed Air Chiller , Industrial Cooling Systems Chillers

China Manufacturer 5 hp Air Cooled Water Chiller Price
Cooling Capacity	kw/h	50Hz	14
		60Hz	16.8
	Kcal/h	50Hz	12057
		60Hz	14468
Temperature Range		3℃ to Room Temperature(below 0℃ can be customized)
Power Supply		3N-380/415V-50/60Hz
Total Power	kw	4.86
Compressor	Type	Hermetic Scroll Type Compressor
	Power (kw)	3.75
Blower	Air Flow Rate (m³/h)	5000
	Power (kw)	0.36
Condenser	Type	Efficient Brass Sets Corrugated Aluminum Fin
Evaporator	Water Flow Rate (m³/h)	50Hz	2.4
		60Hz	2.8
	Pipe Diameter	G 1"
Circulating Pump	Power (kw)	0.75
	Pump Lift (m)	23
Mahine Size	LWH (mm)	12506001250
Weight	kg	170

PID Control Compressed Air Chiller , Industrial Cooling Systems Chillers
