PVC Semi Auto Blowing Machine Making 5 Gallon Carbonated Beverage Bottles

Name: PVC Semi Auto Blowing Machine Making 5 Gallon Carbonated Beverage Bottles
Brand: Eceng
Price: 1 USD

Brand Name : Eceng

Model Number : YC-20L-1

Certification : CE&SGS&ISO

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10 sets per month

Delivery Time : 30 working days

Packaging Details : Film pack

Max volume : 5 gallon

capacity : 120BPH

color : Orange

Cylinder : SMC

PLC : Mitsubishi

warranty : 1 year

Contact Now

Key word

Semi-automatic 5 gallon pet bottle blowing machine

5 gallon pet bottle blowing machine
Pet bottle making machine
bottle making machine

Introductions

Introduction

Our semi-automatic 5 gallon pet bottle blowing machine can produce plastic bottle for 5 gallon , according to the different bottle shape and diameter.
Adopting double crank to adjust mould, heavy locking mould, stable and fast, adopt infrared oven to heat the perform, the perform rotated and heated equally. And the plastic bottles after blowing, are clean, and high quality.

A. Overview

1. Machine name	Semi-automatic 5 gallon pet bottle blowing machine
2. Bottle volume	5 gallon
3. Bottle material	PET,PP,PE,PC
4. Automation	Semi-automatic
5. Producing capacity	100 bottles per hour -adjustable

B. Machine component

Machine name	Semi-automatic 5 gallon pet bottle blowing machine
Machine Model	SBB-100
Producing capacity	Max. 100 bottles per hour
Cavity quantity	1
Bottle material	Pet/PE/PVC
Bottle volume	5 Gallon
Bottle max height	450mm
Bottle max diameter	350mm
Max. mould plate dimension	520600mm(LH)
Max mould thickness	400mm
Clamping force	300KN
Mould opening stroke	330mm
Main machine power	30KW
Electricity supplying	Customized
Main machine dimension	265018002150mm(LWH)
Main machine weight	2MT
Control	Microcomputer
Electrical system	DELIXI
Sensor, Cylineder	China brand

Model type	Tech data
Max. product volume(L/cav)	2	5.5	20	2
Max. preform neck size(mm)	100	150	200	100
Max. product diameter(mm)	180	200	400	180
Max. product height (mm)	300	400	600	300
Cavities	2	1	1	4
Die force (KN)	100	120	150	500
Die stroke (mm)	270	320	340	270
Max. mould size(mm)	390*345	390*350	420*500	460*345
Mould thickness	Adjustable	Mould thickness	Adjustable
Mould spacing(mm	Adjustable	Adjustable	400	120
Max. pulling stroke(mm)	400	500	500	400
Operation pressure(Mpa)	0.8-1.0	0.8-1.0	0.8-1.0	0.8-1.0
Operation air pressure consumption (1tr/min)	200	350	560	200
Blow pressure(Mpa)	1.2-2.8	1.2-2.8	1.2-2.8	1.2-2.8
Blow air pressure consumption (1tr/min)	300	300	650	300
Output(pcs/h	1000-1800	1000-1600	600-900	1000-1800
Machine size(LxWxH)(m)	1.460.581.8	1.560.71.9	2.180.771.96	1.460.581.8
Machine weight(KG)	650	700	1000	650
Temperature grade(rate)	8	8	8	8
Heating time(S)	90-200	90-200	90-200	90-200
Voltage(V)	220 or as your request	220 or as your request	220	220 or as your request
Frequency(HZ)	50/60	50/60	50/60	50/60
Total power(KW)	16	16	15-40	16
Oven Size (LxWxH)	1.350.551.15	1.450.651.15	2.370.681.65	1.350.551.15
Oven weight (KG)	300	330	380	300

PVC Semi Auto Blowing Machine Making 5 Gallon Carbonated Beverage Bottles

Product Tags:

semi automatic pet blowing machine

semi automatic bottle blowing machine

China PVC Semi Auto Blowing Machine Making 5 Gallon Carbonated Beverage Bottles wholesale

PVC Semi Auto Blowing Machine Making 5 Gallon Carbonated Beverage Bottles Images
