Plastic Juice Water Bottle Blowing Machine , Pet Bottle Stretch Blow Molding Machine

Name: Plastic Juice Water Bottle Blowing Machine Pet Bottle Stretch Blow Molding Machine
Brand: Eceng
Price: 1 USD

Brand Name : Eceng

Model Number : k6

Certification : ce，iso

Place of Origin : Zhangjiagang

MOQ : 1

Payment Terms : L/C, T/T, MoneyGram

Delivery Time : 45 days

Packaging Details : woden package

Application : pet bottle making machine

Condition : new

Blow moulding type : stretch blow moulding

Automatic : yes

Voltage : 380V/50HZ

Weight : 6.1tons

material : pet preform

color : black

Contact Now

Plastic Juice Water Bottle Blowing Machine , Pet Bottle Stretch Blow Molding Machine

The automatic blow molding machines have wider wide-mouth capability, faster production rates, and shorter changeover times. Also have features such as preferential heating or heat-setting capability. With our two stage automatic blow molding machines you can produce various different shaped containers, such as mineral water bottle, beverage bottle, cosmetics bottle, medicine bottle, pesticide bottle, edible oil bottle, milk bottle, juice bottle and many more types of PET bottles.

Plastic Juice Water Bottle Blowing Machine , Pet Bottle Stretch Blow Molding Machine

Item	K4	K6	K8
Cavity	4	6	8
Theory output	6000-8500BPH	9000-12000	12000-16000
Max.volume	2L	2L	2L
Bottle mouth maximum overall diameter	28-38mm	28-38mm	28-38mm
Bottle biggest diameter	100mm	100mm	100mm
Bottle maximum height	330mm	330mm	330mm
Light tube quantity	16pcs	32pcs	32pcs
Light tube power	1.25KW	1.25KW	1.5KW
Maximum heating power	20KW	40KW	48KW
All electric machine installation	29KW	49KW	65KW
Actual consumption	30%-60%	30%-60%	30%-60%
Work pressure	5-6kg/c	5-6kg/c	5-6kg/c
Blow bottle pressure	25-45kg/c	25-45kg/c	25-45kg/c
Higher -pressure gas consumption	6000Ltr/min	8000Ltr/min	12000Ltr/min
Work pressure	5-6 kg/c	5-6 kg/c	5-6 kg/c
Temperature range	10ºC	10ºC	10ºC
Consumption	8000kcal/hr	8000kcal/hr	12000kcal/hr
Forzen water flow	30L/min	88L/min	88L/min
Size of the machine	3.61.61.9(m)	4.8x1.6x1.9	5.78x1.6x1.9
Weight of the machine	4.3ton	6.1ton	7.45ton
