6KW Blue Plastic Blow Moulding Machine Making Plastic Bowls / Plates

Product Categories

Zhangjiagang Eceng Machinery Co.,Ltd

Contact Now

6KW Blue Plastic Blow Moulding Machine Making Plastic Bowls / Plates

Name: 6KW Blue Plastic Blow Moulding Machine Making Plastic Bowls Plates
Brand: Eceng
Price: 1 USD

Brand Name : Eceng

Model Number : YC

Certification : CE&SGS&ISO

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5 sets per month

Delivery Time : 45working days

Packaging Details : Film pack

Injection Rate : 62-1175g/s

power : 6KW

color : Blue

warranty : 1 year

material : ss304

Style : Horizontal

Contact Now

6KW Blue Pet Preform Injection Molding Machine Making Plastic Bowls / Plates

INJECTION MACHINE
Injection Unit	Model	A	B
	Screw Diameter	45mm	48mm
	Screw L/D Ratio	1:21.3L/d	1:20l/d
	Injection Volume	273cm3	310cm3
	Shot Weight	248g	282g
	Plasticizing Capacity	27g/s	31g/s
	Injection Pressure	177mpa	155mpa
	Screw Speed	0-200rpm
Clamping Unit	Clamping Force	1500kn
	Opening Stroke	380mm
	Space Between Tie-bars	410*410mm
	Max. Mould Height	420mm
	Min. Mould Height	150mm
	Ejector Stroke	110mm
	Hydraulic Ejection	38mm
General	Pump Pressure	16mpa
	Motor Power	11kw
	Heater	7.5kw
	Machine Dimension(LWH)	41.31.7m
	Machine Weight	3.4t

Specifications

injection molding machine for making plastic bowls / plates / cups / spoons
1.Siemens LCD control
2.Large opening stroke
C

Specifications

injection molding machine for making plastic bowls / plates / cups / spoons
1.Siemens LCD control
2.Large opening stroke
3.usd for pet preform and cap
4.CE,ISO,SGS

Features of injection molding machine for making plastic bowls / plates / cups / spoons :

1) LCD computer control with big display screen
2) Hydraulic double proportional valve
3) Hard chrome plated high tensile strength steel tie bars
4) Generous space for fitting large moulds
5) Large opening stroke
6) Two position transducers to control Clamping and Injection
7) Four stages of injecting, independent velocity and pressure control
8) Hydraulic mould height adjustment device
9) Screw cold-start prevention device
10) Melt decompression control
11) Screw back pressure control
12) Multiple hydraulic ejection
13) Differential high speed clamping
14) Centralized lubrication system
15) Low pressure mould protection device
16) Mechanical safety interlock
17) Double electrical safety interlock
18) Oil return filter
19) Oil tank with inner stainless steel container

6KW Blue Plastic Blow Moulding Machine Making Plastic Bowls / Plates
