Two Cavity Wide Neck Mouth Pet Bottle Blow Molding Machine Fully Auto

Name: Two Cavity Wide Neck Mouth Pet Bottle Blow Molding Machine Fully Auto
Brand: Eceng
Price: 1 USD

Brand Name : Eceng

Model Number : J2

Certification : ce , iso

Place of Origin : Zhangjiagang

MOQ : 1

Payment Terms : L/C, T/T, MoneyGram

Delivery Time : 45 days

Packaging Details : woden package

Application : pet bottle making machine

Condition : new

Blow moulding type : stretch blow moulding

Automatic : yes

Voltage : 380V/50HZ

Weight : 3.5tons

material : pet preform

color : orange

Contact Now

Two Cavity Wide Neck Mouth Pet Bottle Blow Molding Machine Fully Auto

Two-step automatic blow moulding machine is applicable for blowing carbonated beverage bottle, mineral spring water bottle, farm chemical bottle, oil bottle and cosmetic container.

We accroding the characteristics of your products and the production demand to choose the model.

if you have any doubt in choosing machine,you can write to me directly or call me to ask for detailed model of each machine.

I will to reply you asap to help you,we can give you a good suggestion.

Two Cavity Wide Neck Mouth Pet Bottle Blow Molding Machine Fully Auto

Item		J2
Bottle type specification	Cavity	2
	Theory output	1200-1300
	Max.volume	5L
	Bottle mouth maximum overall DIdiameter	150mm
	Bottle biggest diameter	180mm
	Bottle maximum height	400mm
Power specifications	Light tube quantity	32pcs
	Light tube power	1.5KW
	Maximum heating power	48KW
	All electric machine installation	51KW
	Actual consumption	35.7KW
Air pressure specification	Work pressure	7-9kg/cm2
	Low-pressure gas consumption	1600L/min
	Blow bottle pressure	25-35kg/cm2
	Higher -pressure gas consumption	3400Ltr/min
Forzen water specification	Work pressure	5-6 kg/cm2
	Temperature range	10℃
	Consumption	6000kcal/hr
	Forzen water flow	50L/min
Machine specification	Size of the machine	4.7x1.6x1.9
Machine specification	Weight of the machine	3ton

Two Cavity Wide Neck Mouth Pet Bottle Blow Molding Machine Fully Auto
