200ML - 2L Plastic Water Bottle Blowing Machine , Pet Bottle Making Machine

Name: 200ML 2L Plastic Water Bottle Blowing Machine Pet Bottle Making Machine
Brand: Eceng
Price: 1 USD

Brand Name : Eceng

Model Number : k6

Certification : ce，iso

Place of Origin : Zhangjiagang

MOQ : 1

Payment Terms : L/C, T/T, MoneyGram

Delivery Time : 45 days

Packaging Details : woden package

Application : pet bottle making machine

Condition : new

Blow moulding type : stretch blow moulding

Automatic : yes

Voltage : 380V/50HZ

Weight : 6.1tons

material : pet preform

color : black

Contact Now

200ML - 2L Plastic Water Bottle Blowing Machine , Pet Bottle Making Machine

Q Series PET blowing machine is the successful introduction of the latest German technology,with OUR superior design capabilities and manufacturing capacity,to create a high-speed automatic blow molding machine with the international advanced level.

Complete product mainly by blowing host,heating,automatic transmission device,electronic control systems,compressed air systems,and the like.

The machine has high automation,stable performance,high efficiency,low running costs,low failure rate etc.

200ML - 2L Plastic Water Bottle Blowing Machine , Pet Bottle Making Machine

Model		Q6000
Bottle type specification	Cavity	4
	Theory output bph	5500-6500
	Max.volum	2L
	Bottle mouth maximum overall diameter	28-38mm
	Bottle biggest diameter	100mm
	Bottle maximum height	330mm
Power specification	Light tube quantity	40pcs
	Light tube power	1.5KW
	Maximum heating power	60KW
	All electric machine installation	65KW
	Actual consumption	40%--70%
Air pressure specification	Work pressure	7-9kg/cm2
	Low-pressure gas consumption	1600L/min
	Blow bottle pressure	25-35kg/cm2
	Higher -pressure gas consumption	6000Ltr/min
Air pressure specification	Work pressure	5-6 kg/cm2
	Temperature range	10℃
	Consumption	8000kcal/hr
	Forzen water flow	138L/min
Machine specification	Machine size	4.5x2.0x2.3
Machine specification	Machine weight	4.5ton
